オープンCAE勉強会@横浜(2023年8月11日) pimpleFoamを用いた境界層の流れ解析
竹とんぼやドローンなどの物体周りの流れについて、流体力を精度よく解析しようとすると、メッシュ作成方法が重要となります。そこで、基本的な圧力勾配のない平板境界層の流れについて、OpenFOAMのpimpleFoamを用いて、メッシュの作成方法について検討しました。
平板境界層の流れについては、いろいろな取り組みが過去にもされており、OpenFOAMのチュートリアルにも例題があります。それらを参考としています。
話題提供したスライドは以下のようです。
![](https://openscc.com/wp-content/uploads/2023/08/スライド1-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド2-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド3-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド4-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド5-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド6-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド7-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド8-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド9-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド10-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド11-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド12-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド13-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド14-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド15-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド16-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド17-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド18-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド19-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド20-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド21-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド22-1024x576.png)
![](https://openscc.com/wp-content/uploads/2023/08/スライド23-1024x576.png)
勉強会で、nut境界条件の違い影響について質問がありました。追加でnutkWallFunction, nutUWallFunction, nutSpaldingWallFunctionの3つについて計算してみました。ややnutSpaldingWallFunctionが実験値に近いものの3つの境界条件で相違はあまりありませんでした。
![](https://openscc.com/wp-content/uploads/2023/10/pimpleFoam平板境界層流解析-1024x576.png)
